Technical data
Slide pressure
100 to
Back pressure
1 - 27 to
Hydraulic hold down
4 - 31 to
Executon number of columns
4
Support width front
500 mm
Lateral
220 mm
Tool clamping surface:
superior: length
500 mm
Width
470 mm
inferior: length
470 mm
Width
470 mm
Cutting speed:
from
5 mm/s
up to
18 mm/s
Number of strokes:
stepless
from
20 s/min
up to
80 s/min
Voltage 50 Hz 3x
380 Volt
Total power required
10 kW
Machine's weight about
9000 kg
Overall dimensions machine:
Length
1885 mm
Width
1820 mm
Height
2900 mm
Technical specifications and pictures without guarantee.
