Technical data
Min. diameter threaded
2 mm
Max. diameter threaded
50 mm
Min. pitch
0.35 mm
Max. pitch
3 mm
Max. infeed length
85 mm
Min. roll die diameter
120 mm
Roll die width
90 mm
Roller pressure infinitely adjustable
12 to
Roll axis swivel for thru-feed
8 °
Max. working stroke
125 mm
Roll speeds:
stepless
from
30 rpm
up to
150 rpm
Voltage 50 Hz 3x
400 Volt
Motor power
7.5 kW
Connection power
8 kW
Machine's weight about
2000 kg
Overall dimensions machine:
Length
1440 mm
Width
1260 mm
Height
1805 mm
Technical specifications and pictures without guarantee.
